3D
Three-dimensional CADD drawing with defined geometry, used to create detail dimension drawings or simply to illustrate an example.
Glossary
Our industry is full of acronyms and slang / nicknames for things, and this is the page where we are supposed to keep you straight on all of those! We are adding more all the time, slowly but surely!
Glossary Terms
Jump to
3
3D Modeling
The process of generating 3D models (and usually drawings from them).
A
AARH
Arithmetic Average Roughness Height
ASL
Approved Supplier List — A list of approved suppliers / vendors created by procurement using a variety of criteria. These lists associate items and services with companies who supply them. Some of the criteria used to create these lists include, but are not limited to, technology, functionality, financial stability and past performance.
B
BB
BHN Brinell Hardness Number
BBE
Bevel Both Ends (pipe nipple)
BHN
Brinell Hardness Number
Bld.
Blind (flange)
C
conc. red.
Concentric reducer
CADD
Computer Aided Design and Drafting
COC
Certificate of Conformance or Certificate of Compliance — A document that certifies that the supplied goods or services meet the required specifications as outlined by the client and / or project.
E
ecc. red.
Eccentric Reducer
ell
elbow
EOL
elbolet
EOP
End of Pipe
F
Field Assist Drawings (FAD)
Field Assist Drawings are part of Delta’s Total Support Solution (TSS). We add images of all field supports on original ISOs with each shipment. Our FADs help Material Control issue the right material and help craftsmen see where supports are to be installed in the field. We take it one step further and identify all “Tack-Only” supports for safety in handling and to ensure that final field welds are not missed.
F to F
Face to Face
F/F
Face of Flange
F&D
Faced and Drilled
H
HF
Hard Faced
HFC
Hard-Faced Seats
L
LEB
Large End Beveled (swage)
LEP
Large End Plain (swage)
LET
Large End Threaded (swage)
LOL
Latrolet
M
MTR
Material Test Report or Mill Test Report — A quality-assurance document that certifies that the chemical analysis and physical properties of the material are in conformance with appropriate ASTM standards. MTRs include the name of the manufacturer, heat number, grade of material, dimensional information, chemical composition analysis results, country of origin, etc.
N
NPS
Nominal Pipe Size
NPT
National Pipe Taper
NRS
Non-Rising Stem (valve)
O
OS&Y
Outside Screw and Yoke (valve)
P
PBE
Plain Both Ends (pipe nipple)
PE
Plain End (pipe nipple)
POE
Plain One End (pipe nipple)
R
RCP
Reinforced Concrete Pipe
RF
Raised Face
RJ
Ring Joint (flange)
RS
Rising Stem (valve)
S
SO
Slip-On (flange)
SEB
Small End Beveled (swage)
SEP
Small End pPlain (swage)
SET
Small End Threaded (swage)
T
Total Support Solution (TSS)
Delta's suite of services that begins with ISO Take-off , identification of all needed supports, CAD drawings, material take-off, standard pricing, all needed supports, drawings, special packaging, prioritization, pre-buy-tracking, the works! We make supports worry-free!
TBE
Thread Both Ends (pipe nipple)
TOE
Thread One End (pipe nipple)
TOL
Threadolet
W
WOG
Water, Oil and Gas
WN
Weldneck (flange)
WOL
Weldolet
X
XH
Extra Heavy (pipe schedule)
XXH
Double Extra Heavy (pipe schedule)
